| Manufacturer | STMicroelectronics |
| Manufacturer Standard Lead Time | 25 Weeks |
| Description | IC CMOS 2 CIRCUIT 8SOIC |
| Package | Tape & Reel (TR), Cut Tape (CT) |
| Product Status | Active |
| Output Type | Rail-to-Rail |
| Operating Temperature | -40°C ~ 125°C |
| Base Product Number | TSV622 |
| Package / Case | 8-SOIC (0.154″, 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Mounting Type | Surface Mount |
| Amplifier Type | CMOS |
| Number of Circuits | 2 |
| Slew Rate | 0.14V/µs |
| Gain Bandwidth Product | 420 kHz |
| Current – Input Bias | 1 pA |
| Voltage – Input Offset | 800 µV |
| Current – Supply | 29µA |
| Current – Output / Channel | 74 mA |
| Voltage – Supply Span (Min) | 1.5 V |
| Voltage – Supply Span (Max) | 5.5 V |
- The TSV622AIDT integrates two independent operational amplifiers within a single package. This dual configuration is advantageous in applications requiring multiple amplification stages or dual-channel signal processing.
- One of the primary features of the TSV622AIDT is its low power consumption, drawing only 29 microamperes (29uA) of current.
- The TSV622AIDT supports rail-to-rail input and output operation. This feature allows the op-amp to handle signals that swing close to both the positive and negative supply rails, maximizing the dynamic range of amplified signals.
