| Manufacturer | Infineon |
| Series | OptiMOS-T2 |
| Qualification | AEC-Q101 |
| Packaging | MouseReel |
| Brand | Infineon Technologies |
| Product Type | MOSFET |
| Factory Pack Quantity | 2500 |
| Tradename | OptiMOS |
| Technology | Si |
| Mounting Style | SMD/SMT |
| Package / Case | TO-252-3 |
| Transistor Polarity | N-Channel |
| Number of Channels | 1 Channel |
| Vds – Drain-Source Breakdown Voltage | 40 V |
| Id – Continuous Drain Current | 50 A |
| Rds On – Drain-Source Resistance | 6.2 mOhms |
| Vgs – Gate-Source Voltage | – 16 V, + 20 V |
| Vgs th – Gate-Source Threshold Voltage | 1.2 V |
| Qg – Gate Charge | 30 nC |
| Minimum Operating Temperature | – 55 C |
| Maximum Operating Temperature | + 175 C |
| Pd – Power Dissipation | 46 W |
| Channel Mode | Enhancement |
| Configuration | Single |
| Fall Time | 18 ns |
| Height | 2.3 mm |
| Length | 6.5 mm |
| Rise Time | 8 ns |
| Transistor Type | 1 N-Channel |
| Typical Turn-Off Delay Time | 11 ns |
| Typical Turn-On Delay Time | 4 ns |
| Width | 6.22 mm |
| Part # Aliases | SP000711456 IPD5N4S4L8XT IPD50N04S4L08ATMA1 |
| Unit Weight | 0.011640 oz |
