| Manufacturer | Infineon |
| Packaging | MouseReel |
| Brand | Infineon Technologies |
| Product Type | MOSFET |
| Factory Pack Quantity | 1000 |
| Technology | Si |
| Mounting Style | SMD/SMT |
| Package / Case | TO-263-3 |
| Transistor Polarity | N-Channel |
| Number of Channels | 1 Channel |
| Vds – Drain-Source Breakdown Voltage | 40 V |
| Id – Continuous Drain Current | 100 A |
| Rds On – Drain-Source Resistance | 2.5 mOhms |
| Vgs – Gate-Source Voltage | – 20 V, + 20 V |
| Vgs th – Gate-Source Threshold Voltage | 2.1 V |
| Qg – Gate Charge | 172 nC |
| Minimum Operating Temperature | – 55 C |
| Maximum Operating Temperature | + 175 C |
| Pd – Power Dissipation | 300 W |
| Channel Mode | Enhancement |
| Configuration | Single |
| Fall Time | 33 ns |
| Height | 4.4 mm |
| Length | 10 mm |
| Rise Time | 46 ns |
| Transistor Type | 1 N-Channel |
| Typical Turn-Off Delay Time | 56 ns |
| Typical Turn-On Delay Time | 27 ns |
| Width | 9.25 mm |
| Part # Aliases | SP000219061 IPB100N04S204ATMA1 |
| Unit Weight | 0.139332 oz |
