| Manufacturer | STMicroelectronics |
| Description | IC PWR DRIVER N-CHANNEL 1:8 20SO |
| Package | Tape & Reel (TR), Cut Tape (CT) |
| Product Status | Active |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 20-SOIC (0.295″, 7.50mm Width) |
| Supplier Device Package | 20-SO |
| Base Product Number | E-L9826 |
| Manufacturer Standard Lead Time | 52 Weeks |
| Voltage – Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Switch Type | Latched Driver |
| Number of Outputs | 8 |
| Ratio – Input:Output | 1:8 |
| Output Configuration | Low Side |
| Output Type | N-Channel |
| Interface | SPI |
| Voltage – Load | 45V (Max) |
| Current – Output (Max) | 450mA |
| Rds On (Typ) | 1.5Ohm |
- As a low-side driver, the E-L9826TR is designed to control the grounding (low side) of connected loads. This configuration is commonly used in automotive applications to control various actuators and devices.
- Featuring eight low-side driver channels, the E-L9826TR provides flexibility for controlling multiple loads simultaneously. This is advantageous in automotive applications where numerous actuators or components may require individual control.
- The E-L9826TR may include protection features such as overcurrent protection and thermal shutdown. These features enhance the robustness of the device and contribute to its ability to withstand challenging operating conditions.
- The E-L9826TR is suitable for a range of automotive applications, including but not limited to powertrain control, body electronics, and safety systems. It can be employed to control various loads within the vehicle, contributing to the overall functionality and performance.
